Description

WellWater Hudson pump stations are Ø1.2m vertical units, available from 2000mm to 3500mm heights with storage capacities ranging from 2170 litres to 3860 litres.

Each system is supplied as a complete unit with either single or twin submersible pumps with guide rails and high-quality internal pipework/fittings as standard.

These pump stations are typically used in medium to large domestic or commercial applications for pumping foul water or sewage to the mains sewer.

All packaged pumping stations are available as single or twin pumps & for sewage and effluent.

KEY

1. Inlet
2. Submersible pump(s) – Single or twin free-standing options
3. Pump retrieval chain
4. Non-return valve(s)
5. Gate valve
6. Outlet connection
7. Ducting and cable entry points
8. Vent
9. Manway access
10. Float bracket

Float configuration options
A. Pump ‘OFF’ float switch
B. Pump 1 ‘ON’ float switch
C. Pump 2 ‘ON’ float switch (on twin pump configurations)
D. High water float switch

Note: Floats can be fitted directly to specific pump systems. Please contact Marsh Industries to discuss your project requirements.

Benefits

• Designed to British Standard European Norm’s:
  BSEN12050 for structural strength and water-tightness
  BSEN752 to comply with hydrostatic and electrical requirements
  BSEN752-6 for drain and sewer systems in outside buildings
• Smooth internal walls and integral pump well improves pump efficiency and eliminates ‘dead spots’ which can lead to odours and septicity
• Variable invert depths and orientations ­­­to suit individual site conditions
• Pre-assembled pipework for fully automatic operation
• Unique ‘keying-in’ lip on WellWater:Seine range assists anchoring into concrete surround

Specification

• Sewage - 110mm or 160mm pipe work diameter
