Description
WellWater Amazon pump stations are Ø2.5m horizontal units, available in storage capacities ranging from 7710 litres to 100,000 litres.
Each system is supplied as a complete unit with either twin submersible pumps with guide rails and high quality internal pipework/fittings as standard.
These pump stations are typically used in extra large domestic or commercial applications for pumping foul water or sewage to mains sewer.
All packaged pumping stations are available as twin pumps & for sewage.
KEY
- Inlet
- Submersible pump(s) – Single or twin free-standing options
- Pump retrieval chain
- Non-return valve(s)
- Gate valve
- Outlet connection
- Ducting and cable entry points
- Vent
- Manway access
- Float bracket
Float configuration options
A. Pump ‘OFF’ float switch
B. Pump 1 ‘ON’ float switch
C. Pump 2 ‘ON’ float switch (on twin pump configurations)
D. High water float switch
Note: Floats can be fitted directly to specific pump systems. Please contact Marsh Industries to discuss your project requirements.
Benefits
- Designed to British Standard European Norm’s:
BSEN12050 for structural strength and water-tightness
BSEN752 to comply with hydrostatic and electrical requirements
BSEN752-6 for drain and sewer systems in outside buildings - Smooth internal walls and integral pump well improves pump efficiency and eliminates ‘dead spots’ which can lead to odours and septicity
- Variable invert depths and orientations to suit individual site conditions
- Pre-assembled pipework for fully automatic operation
- Unique ‘keying-in’ lip on WellWater:Seine range assists anchoring into concrete surround
Specification
- Sewage - 110mm or 160mm pipe work diameter
